Metal Door Frame Roll Forming Machines

Metal Door Frame Roll Forming Machines

We are a leading Manufacturer of Metal Door Frame Roll Forming Machines, delivering precision-engineered roll forming solutions for the production of steel door frames, fire-rated door frames, window frames, and customized structural frame profiles used in residential buildings, commercial complexes, hospitals, schools, industrial facilities, and modular construction projects. Our machines are designed to ensure dimensional accuracy, smooth edge finishing, and consistent profile formation.

Metal door frames require high precision and structural integrity to ensure proper installation, alignment, and long-term durability. Our roll forming machines are developed using advanced CAD-based tooling design and precision roll forming technology, allowing accurate bend angles, uniform profile shaping, and tight tolerance control. The machines can process CR steel, GI, PPGI, stainless steel, and other coated sheets, typically ranging from 0.8 mm to 2.0 mm thickness.

The complete production line includes hydraulic decoiler, sheet leveling system, servo feeding unit, punching system for hinge slots and lock holes, multi-stage roll forming stations, hydraulic cutting system, and profile receiving table. The punching system ensures precise hole alignment and repeatability for hinges, locks, and fixing points.

Equipped with PLC-based automation and HMI touchscreen controls, the machine allows operators to set frame length, punching position, and profile parameters with high accuracy. The heavy-duty base frame, hardened forming rolls, and precision-ground shafts ensure vibration-free operation and long machine life.

Each machine undergoes comprehensive trial production runs, dimensional inspection, punching alignment checks, bend angle verification, and electrical safety validation before dispatch.

Key Technical Specifications

1. Material Thickness Range: 0.8 mm – 2.0 mm

2. Material Type: CR / GI / PPGI / Stainless Steel

3. Production Speed: 10–20 meters per minute

4. Forming Stations: 12–18 stations

5. Main Motor Power: 10 HP – 20 HP

6. Hydraulic Power Unit: 5 HP – 10 HP

7. Punching System: Hydraulic / CNC Punching

8. Cutting System: Hydraulic Cut-Off

9. Control System: PLC with HMI Touchscreen

10. Drive Type: Chain Drive / Gear Drive

11. Shaft Diameter: 60–80 mm hardened shafts

12. Roll Material: D3 / D2 hardened rolls

13. Decoiler Capacity: 3–5 Ton hydraulic decoiler

14. Length Accuracy: ±1 mm

15. Profile Type: Single / Double Rebate / Custom Frames

Our Metal Door Frame Roll Forming Machines are engineered for high precision, smooth finishing, structural consistency, and long-term production reliability—ideal for modern building material manufacturing industries.
