Roofing Sheet Roll Forming Machines

Roofing Sheet Roll Forming Machines

We are a leading Manufacturer of Roofing Sheet Roll Forming Machines, delivering high-performance and precision-engineered roll forming solutions for producing corrugated roofing sheets, trapezoidal sheets, color-coated roofing panels, industrial roofing profiles, and metal cladding sheets. Our machines are designed to support construction, PEB structures, warehouses, commercial buildings, industrial sheds, and infrastructure projects requiring high-quality roofing systems.

Our roofing sheet roll forming machines are engineered using advanced CAD-based profile design and precision roll tooling technology, ensuring accurate sheet formation, uniform corrugation depth, and superior surface finish. The machines are capable of processing GI, PPGI, PPGL, aluminum, CR/HR steel sheets, and other coated materials.

The complete production line includes hydraulic decoiler, sheet leveling system, servo feeding unit, multi-stage roll forming stations, hydraulic or servo cutting system, and automatic sheet run-out table. With PLC-based automation and HMI touchscreen control, operators can easily set sheet length, production speed, and cutting parameters.

Our machines are built with heavy-duty base frames, hardened shafts, and precision-ground forming rolls to ensure vibration-free operation, high-speed production (up to 30 meters per minute), and long service life. We also offer customization for different roofing profiles as per client drawings and market requirements.

Each machine undergoes rigorous trial production runs, profile accuracy inspection, sheet thickness verification, cutting precision checks, and electrical safety validation before dispatch.

Key Technical Specifications

1. Material Thickness Range: 0.3 mm – 1.2 mm

2. Material Width Capacity: Up to 1250 mm

3. Production Speed: 15–30 meters per minute

4. Forming Stations: 12–18 stations

5. Main Motor Power: 7.5 HP – 20 HP

6. Hydraulic Power Unit: 5 HP – 10 HP

7. Cutting System: Hydraulic / Servo Fixed-Length Cutting

8. Control System: PLC with HMI Touchscreen

9. Drive System: Chain Drive / Gear Drive

10. Shaft Diameter: 60–80 mm hardened shafts

11. Roll Material: D3 / D2 hardened steel rolls

12. Decoiler Capacity: 5 Ton hydraulic decoiler

13. Sheet Length Accuracy: ±1 mm

14. Profile Type: Corrugated / Trapezoidal / Custom

15. Power Supply: 415V, 3-Phase, 50 Hz (customizable)

Our Roofing Sheet Roll Forming Machines are designed to deliver high productivity, dimensional precision, low maintenance, and long-term durability—making them ideal for modern roofing sheet manufacturing businesses.
