Standing Seam Roof Panel Machines

Standing Seam Roof Panel Machines

We are a leading Manufacturer of Standing Seam Roof Panel Machines, delivering advanced roll forming solutions for producing high-performance standing seam roofing panels used in commercial buildings, industrial facilities, airports, railway stations, malls, PEB structures, warehouses, and architectural projects. Our machines are engineered for superior panel accuracy, weather resistance, and long-term structural performance.

Standing seam roofing systems are widely recognized for their concealed fastener design, leak-proof performance, wind resistance, and aesthetic architectural finish. Our machines are designed using precision CAD-based tooling systems to ensure consistent seam formation, tight interlocking joints, and smooth panel surfaces. They are capable of processing PPGI, PPGL, aluminum, zinc-coated steel, and high-tensile metal sheets.

The production line includes hydraulic decoiler, sheet leveling system, servo feeding unit, multi-stage roll forming stations, seam locking profile formation system, hydraulic cutting system, and run-out support table. We also offer optional on-site portable standing seam machines suitable for long-length roofing panel production directly at project locations.

Our machines feature PLC-based automation with HMI touchscreen controls, allowing operators to adjust panel width, seam height, and cutting length with high precision. The heavy-duty frame structure, hardened forming rolls, and precision shafts ensure vibration-free operation and consistent production speeds up to 20 meters per minute.

Each machine undergoes comprehensive trial production, seam locking validation, dimensional inspection, wind-load profile verification, and electrical safety checks before dispatch.

Key Technical Specifications

1. Material Thickness Range: 0.4 mm – 1.2 mm

2. Material Type: PPGI / Aluminum / GI / Zinc Sheets

3. Production Speed: 10–20 meters per minute

4. Forming Stations: 14–20 stations

5. Main Motor Power: 10 HP – 25 HP

6. Hydraulic Power Unit: 5 HP – 10 HP

7. Cutting System: Hydraulic / Servo Cut-Off

8. Seam Height Options: 25 mm – 65 mm

9. Panel Width: Customizable (as per design)

10. Control System: PLC with HMI Touchscreen

11. Drive System: Chain / Gear Drive

12. Shaft Diameter: 70–90 mm hardened shafts

13. Decoiler Capacity: 5 Ton hydraulic decoiler

14. Length Accuracy: ±1 mm

15. Power Supply: 415V, 3-Phase, 50 Hz

Our Standing Seam Roof Panel Machines deliver high structural precision, leak-proof seam locking, architectural excellence, and long-term durability—making them ideal for modern roofing and large-scale infrastructure projects.
