Solar Profile Roll Forming Machines

Manufacturer of Solar Profile Roll Forming Machines

We are a leading Manufacturer of Solar Profile Roll Forming Machines, delivering high-precision and high-efficiency roll forming solutions for the production of solar mounting strut channels, C-channels, Z-profiles, omega profiles, rails, and customized solar structural sections. Our machines are engineered to meet the growing demands of utility-scale solar plants, rooftop solar systems, solar carports, and ground-mounted PV structures, ensuring consistent profile accuracy and superior production performance.

Our solar profile roll forming machines are designed using advanced CAD/CAM engineering software and manufactured with precision-machined components to guarantee dimensional accuracy, high-speed production, and long-term operational reliability. The machines are suitable for processing GI (Galvanized Iron), Pre-Galvanized Steel, HR/CR Steel, and other coated sheets used in solar mounting structures.

? Key Technical Specifications:

• Material Thickness Range: 1.5 mm to 3.0 mm (customizable)

• Material Width Capacity: As per profile design (typically 100–400 mm)

• Production Speed: 10–25 meters per minute (depending on profile complexity)

• Number of Forming Stations: 10 to 18 stations (as per profile requirement)

• Main Motor Power: 7.5 HP to 22 HP (depending on machine size)

• Hydraulic Power Unit: 5 HP to 10 HP

• Cutting System: Hydraulic / Servo-driven flying cut-off system

• Punching System: Pre-punch / Post-punch hydraulic punching unit (optional CNC punching)

• Control System: PLC-based automation with HMI touchscreen interface

• Drive System: Chain drive / Gear drive system with synchronized shafts

• Decoiler Capacity: 3–5 Ton hydraulic or manual decoiler

Our machines are equipped with automatic length measurement systems, precision roll tooling, hardened shafts, heavy-duty base frames, and adjustable forming stands to ensure stable and vibration-free operation. We offer both fully automatic and semi-automatic production lines, depending on customer requirements.

The production process includes coil loading → leveling & feeding → punching → progressive roll forming → profile shaping → hydraulic cutting → finished profile discharge. Each stage is synchronized through PLC-based controls to maintain uniform profile geometry, minimal tolerance deviation, and reduced material wastage.

We emphasize structural strength and corrosion resistance compliance, ensuring that the produced solar strut channels meet international solar EPC and structural standards. Our machines are optimized for high material utilization, low downtime, reduced rejection rates, and energy-efficient performance, making them ideal for medium and large-scale manufacturing facilities.

Before dispatch, every roll forming machine undergoes trial production runs, profile dimension verification, punching alignment checks, load testing, and electrical safety validation to ensure reliable performance at the client site.

We provide complete installation, commissioning, operator training, and after-sales technical support, ensuring seamless plant setup and long-term operational stability.

Our Solar Profile Roll Forming Machines are designed to enhance production capacity, dimensional precision, automation efficiency, and long-term durability—making them a trusted solution for solar structure manufacturers worldwide.
